STX165 Mode C Transponder Panel Mount

Código: DL00170

Fabricante: Dallas Avionics

Dallas Avionics


A New Standard In Transponders The STX 165 and STX 165R elevate transponder capability to a new level while reducing both weight and size. The solid state transmitter design provides 200 Watts nominal output with no warm up time. And because it's all solid state, power requirements are at an absolute minimum.

STX 165 is a panel mount unit that uses a 1/2 3ATI panel cutout. Behind the panel depth is only 6 1/4" (not including connectors). With a built in Altitude encoder, installation time and cost is greatly reduced. The optional OAT Probe input provides additional capability including density altitude and OAT displays and icing alerts.
